MPPT Solar Controller (12V/24V, 35A)

Description

• Product Name: MPPT Solar Controller
• Model No: MPPT135A124
• Charging Capacity: 35 Amp
• Solar Capacity: 500W / 1000W
• Solar Range: 100 VOC
• Battery Voltage: 12V / 24V
• Input Energy Source: Solar
• Price: ₹4979 + GST
• Service Warranty: 12 Months

Protection Features:

• Overcharging Protection
• Overcurrent Protection
• Overheat Protection
• Battery Full Charge Cut-off: 14.7V / 29.4V
• Short Circuit Protection

Working Mechanism:

• This device operates solely on solar power and does not support AC voltage supply.
• It charges the battery directly from the solar panel.

Service Warranty:

• This product includes a one-year free service period but is not eligible for replacement.
• For service, testing, or repairs, the consumer must take the product to the company’s authorized service center, dealer, or distributor.
• Alternatively, the product can be sent directly to the company via courier or transport service. The cost of transportation and any associated risks during transit will be borne by the customer.
• The warranty will be void if the defect is caused by:
• Accidental damage
• Misuse or negligence
• Incorrect installation or dismantling
• Servicing by unauthorized personnel
• Customers must report defects via Help & Support option in App or alternatively using company’s service number - +91-7465005001
• During the warranty period, there will be no service charge or part replacement fee.
• After the warranty expires, service and replacement parts will be chargeable.

Safety Instructions:

Please follow the instructions carefully before connecting the solar controller.

• In case of an emergency, turn off the product and disconnect the cord from at least one battery terminal.
• Ensure that no foreign particles, water, or other liquids enter the product.
• When connecting or disconnecting the battery bank, avoid physical contact with it.
• Never open the product cover, as high voltage is present inside the solar controller, even when turned off.
